Low Toxicity Fm200 Fire Suppression System Electric Insulation
Parameter:
| No. | specification | Technical Parameter | |
| 1 | Filling pressure | 4.2Mpa | |
| 2 | Scale of Protective region for one zone | area:max single-zone is 800m² volume:max single-zone is 3600m³ | |
| 3 | Spraying time | ≤10s | |
| 4 | Filling density | ≤950kg/m3 | |
| 5 | power | DC24V/1.6A | |
| 6 | Nitrogen Pressure of Driving Device | 6.0±1.0Mpa(20℃) | |
| 7 | Condition of reserving room for container | temperature: -10~50℃, relative humidity: ≤97% | |
| 8 | max working pressure | 5.3Mpa | |
| 9 | min working pressure | 4.2Mpa | |
Description:
Though Fm200 is a new and small part of the gas fire-fighting, it becomes more and more popular all over the world. Because of its born advantages-odorless, colorless and nontoxic, fm200 fire suppression system is considered as the best substitute of the popular series of halon type fire suppression system. The most attractive point is that the fm200 fire suppression system has no damage to the ozone layer, even just 1% possibility. Though the whole system looks very complicated, actually it is easy installation.
This fm200 fire fighting equipment only fits the occupied room or places, because it uses whole flooding way to extinguish the fire.
Competitive Advantages:
1. clean gas agent
2. colorless, tasteless, low toxicity, and non-conductive
3. no residue or oily deposits
4. small storage space and easily pressurized in cylinder
5. compliance with environmental protection requirement
6. Large range of application area
7. Management of multiple zones
8. Efficient fire protection in big region
Simulated diagram:
Below attached is one mimic diagram of piped network type of fm200 automatic fire suppression system, in this mimic diagram, you can see clearly how the pipe fitting equips and how will the whole system look like when it has already finished.
Composition:
Pipe network fm200 fire suppression device is composed of the following components: fm200 agent, fm200 cylinders, container valves, flexible hoses, liquid flow check valves, a set of manifold, a safety valve, pressure switch, nitrogen driving device(s), driving device frame, gas control pipe, gas flow check valves(it depends), selective valves(it depends), a pair of elbows and flanges, nozzles.If one set device needs to protect multiple protected zones, its composition is as above. However, if one set system just needs to protected single protected zone, the gas flow check valve and selective valve should be got rid of from its composition.
Company Introduction:
Guangzhou Xingjin Fire Equipment Co., Ltd., which is situated in Guangzhou, which is a key hub for communication between China and the rest of the globe, is surrounded by easy access to transit and a stunning natural environment. We are a manufacturer, and our professional and experienced staff, which includes the program design team, the skillful installation team, the quality detecting team, and the after-sell service team, devotes its time to the study and development of HFC-227ea (FM200) products. The pipe network FM200 fire suppression system, the cabinet type FM200 fire suppression system, the automatic FM200 fire extinguisher (ceiling mounted style), the fire detecting tube suppression system, and the automatic fire suppression tube are currently among the most commonly utilized of our well-known FM200 products. As a result of high-quality products and services as well as the good reputation, our company is well-received by the customers in China.
Part Cases Show:
• In Sichuan province, the project cases are Bei Xin Run Yuan, Dong Lu Yi Jing, Yuewang Tower, Times Flower City, Shude Middle School, Wal - Mart near ASCB, New Hope Building, Xin Yi Zi Jin City, Tobacco Building, etc.
• In Guangdong province, the project cases are GAC Group, 10086 in Shenzhen, Haizhu Industrial and Commercial Bureau, Wanbao Air Controller, Yingfu Building in Shenzhen, Bank of Communication in Zhanjiang, Lijin Square in Zhanjiang, Zhanjiang Broadcasting and TV Station, etc.
• In Shandong province, the project cases are Lushang Office Building, Lushang Marketing Center, etc.
Why Choose Us
• 5 years quality guarantee
• Xingjin is running in a high efficiency management system
• Advanced equipments & professional engineers to promise all products are quite satisfactory.
• We provide 8×6 hrs technical support and service.
After-Sale Service
• We have an efficient sales and after sales team to promise slove all client's question in time.
• We provide 8×6 hrs technical support and service.
FAQ
Q1: Are you a trading company or a manufacturing, first?
A1: We are a producer.
Q2: Do OEM items exist?
A2: Your own artwork and design are appreciated.
Q3: Where is your factory located? Can I go there?
A3: Shilou, Panyu, Guangzhou, Guangdong, China is where our factory is located. Yes, of course. We always look forward to seeing you.
Q4: How can I get to your plant ?
A4: You can take a taxi or take the subway to get here because of how easily it can be reached. If arriving by subway, you must take the line 4 and alight at the Shiqi station. Take the No. 126 bus out of the station after that, and get off at Yuexi station.
